Shopify write-back actions

If your chatbot is connected to a Shopify store (Deploy on Shopify), four Shopify write-back actions become available in the Action Template Picker. They cover the most common e-commerce support flows — and they reuse the existing Shopify OAuth, so no extra setup is required.

In this guide:

• The four actions
• Use them in the Action Builder
• Destructive flags
• PII handling
• Limitations

The four actions

Step 1: Open the Template Picker

On your chatbot detail page → Actions → New action → Template Picker → Shopify section.

Screenshot: The Shopify section of the Template Picker showing the four write-back presets.

Click any of the four presets. The Action Builder opens pre-filled with:

• Endpoint pointing at the relevant Shopify proxy route.
• Method, JSON input schema, and prompt.
• destructive flag (true for cancel and update_order_note).
• rate_limit_rpm set to a sensible default.

Step 2: Save and use

Save. The bot will use the action when conversation context calls for it. Examples:

• “Where’s my order #1023?” → shopify-get-order → returns status, line items, fulfillment.
• “I’d like to cancel order #1023.” → shopify-cancel-order → confirmation card → cancel.
• “Add a note to my order to leave at the back door.” → shopify-update-order-note → confirmation card → note added.
• “Do you have the red XL in stock?” → shopify-check-inventory → returns quantity or “out of stock.”

Cancel-order semantics

shopify-cancel-order is idempotent:

• First call → cancels the order, returns 200.
• Second call on the same already-cancelled order → returns 200 with the order’s current state, not 409.

This avoids confusing users when a network retry triggers a second cancel.

A default cancel reason (“cancelled via chatbot”) is applied when none is provided.

PII safety in update-order-note

When the user dictates a note (“Please leave it at the back door, my dog’s name is Rex”), the note text is not logged to the audit log — only order_id and the operation mode (replace, append, prepend).

This protects against accidental PII leaks in audit-log exports.

Architecture

These actions don’t talk directly to Shopify from your browser. Each call:

1. Goes to a Hilal Next.js proxy route (e.g., POST /api/shopify/actions/cancel_order).
2. The proxy validates the user’s session and signs the request.
3. The signed request hits Hilal’s backend with organization_id.
4. The backend calls Shopify’s Admin API using the store’s stored OAuth token.
5. The response transforms snake_case to camelCase and flows back.

This keeps Shopify credentials server-side and gives the proxy a place to enforce per-action authorization.

Limitations

• One store per chatbot. Multi-store setups need multiple chatbots.
• No bulk operations, refunds, or partial cancels. These need follow-up actions.
• No line-item editing. Order modification is limited to notes and full cancel — line-item changes need Shopify’s Draft Order API (custom action territory).

Permissions and feature flag

These actions become available automatically when the chatbot is connected to a Shopify store. No separate feature flag.

For the proxy routes:

• shopify_actions.read — get_order, check_inventory
• shopify_actions.write — cancel_order, update_order_note (destructive)

Troubleshooting

• “Unauthorized” on every call. The Shopify OAuth token may be missing or expired — reinstall the Shopify app.
• “Order not found.” Verify the order number format — strip the leading # if present (the proxy already does this).
• check-inventory returns null. The SKU isn’t tracked in Shopify’s inventory. Not an error.
